Alienware Graphics Amplifier with 40 Series GPU's


Maxware79

Recommended Posts

Someone posted this on Reddit this week so it may be helpful for some of you.







Alienware Aurora R15 - i9-13900KF - RTX 4090 - 32GB DDR5

Alienware M18x R2 - i7-3920XM - GTX 970M - 16GB 1866Mhz DDR3L - Samsung 970 Evo with MXM to NVMe Adapter - Custom Delft Blue

Alienware X51 - i7-3770 - NO GPU - 16GB 1600Mhz DDR3  Alienware M17x R3 - i7-2760QM - GTX 580M - 16GB 1600Mhz DDR3

Alienware Area 51 ALX - i7-975 Extreme - GTX 980 - 16GB 1600Mhz DDR3   Alienware Aurora R2 - i7-3770K - GTX 670FTW - 16GB 1600Mhz DDR3

Alienware Aurora R4 ALX - i7-3930K - GTX 1060 - 16GB 1600Mhz DDR3        Alienware Aurora R4 ALX - i7-3930K - GTX 670FTW - 16GB 1600Mhz DDR3



Link to comment
Share on other sites

Just to copy/paste in the event that post ever gets deleted or something:



Further reading of experiences around the AGA in this and other forums, made me even try the plug and unplug technique proven to work by some users with the 3000 series (https://www.dell.com/community/Alienware/PCI-e-3-0-x4-for-ampere-3080-3090-question/m-p/7894720#M43691), however I had no luck until I did the following:

  • Uninstalled AWCC using Revo uninstaller (advanced scan and deleting found entries is mandatory after uninstalling)

  • Restarted system

  • Uninstalled Nvidia drivers

  • Restarted system

  • Installed the Chipset INF utility

  • Restarted the system

  • Located the following subkey in regedit HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\PnP\Pci

  • Generated the HackFlags entry with a value data of 200 as depicted here (https://learn.microsoft.com/en-us/troubleshoot/windows-client/deployment/error-attach-pci-express-expansion-chassis)

  • Reinstalled Nvidia drivers using the latest package

  • Restarted system

  • The card was still being detected as “Microsoft Basic Display Adapter”, so I uninstalled the Nvidia drivers

  • Restarted the system

  • Generated the HackFlags entry with a value data of 400 as previously described (this value worked for me)

  • Reinstalled Nvidia drivers

  • Restarted the system

  • After restarting, the card was outputting video and recognized as NVIDIA GeForce RTX 4070 Ti

  • Reinstalled the latest AWCC

  • Restarted the system

  • After restarting, the card and AGA were also being recognized in the AWCC



Important notes:

  1. The HackFlags entry never worked for me until I uninstalled the NVIDIA drivers each time I modified the subkey; for this reason I suggest testing systematically the 200, 400 and 600 values always uninstalling and reinstalling.

  2. Apparently AWCC can interfere with process since I tried everything depicted below and it did not work until AWCC was uninstalled.

  3. The AGA and card were connected to my laptop the whole time

Alienware m18             : Intel Core i9 13900HX                  | nVidia GeForce RTX 4090    | K1675 | 2x1TB SSDs

Alienware Area-51M : Intel Core i9-9900K @ 5.3Ghz    | nVidia GeForce RTX 2080    | AX210 | Samsung 970 Evo+
Alienware M18x R2 :    Intel Core i7 3920XM @ 4.7Ghz | nVidia Quadro RTX 3000     | AX210 | Samsung 980 PRO
Clevo X170SM-G:         Intel Core i7 10700K @ Stock     | nVidia GeForce RTX 2070S | AX210 | 256GB+2x512GB

More Laps: M14x (555m) | M14xR2 (650m) | M15x (980m) | M17xR3 (880m) | M18xR1 (880m SLI) | 18 R1 (RTX 3000)

DT: Aurora R4 (i9 10980XE/RTX 4070) | Area-51 R2 (22-Core Xeon/2x Titan V) | SR-2 [2x6-Core/3x980Ti] | Mac Studio


CS Studios YouTube: https://www.youtube.com/c/CSStudiosYT

Link to comment
Share on other sites

  • 3 weeks later...
On 1/12/2023 at 4:29 PM, ssj92 said:

Just to copy/paste in the event that post ever gets deleted or something:



Further reading of experiences around the AGA in this and other forums, made me even try the plug and unplug technique proven to work by some users with the 3000 series (https://www.dell.com/community/Alienware/PCI-e-3-0-x4-for-ampere-3080-3090-question/m-p/7894720#M43691), however I had no luck until I did the following:

  • Uninstalled AWCC using Revo uninstaller (advanced scan and deleting found entries is mandatory after uninstalling)

  • Restarted system

  • Uninstalled Nvidia drivers

  • Restarted system

  • Installed the Chipset INF utility

  • Restarted the system

  • Located the following subkey in regedit HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Control\PnP\Pci

  • Generated the HackFlags entry with a value data of 200 as depicted here (https://learn.microsoft.com/en-us/troubleshoot/windows-client/deployment/error-attach-pci-express-expansion-chassis)

  • Reinstalled Nvidia drivers using the latest package

  • Restarted system

  • The card was still being detected as “Microsoft Basic Display Adapter”, so I uninstalled the Nvidia drivers

  • Restarted the system

  • Generated the HackFlags entry with a value data of 400 as previously described (this value worked for me)

  • Reinstalled Nvidia drivers

  • Restarted the system

  • After restarting, the card was outputting video and recognized as NVIDIA GeForce RTX 4070 Ti

  • Reinstalled the latest AWCC

  • Restarted the system

  • After restarting, the card and AGA were also being recognized in the AWCC



Important notes:

  1. The HackFlags entry never worked for me until I uninstalled the NVIDIA drivers each time I modified the subkey; for this reason I suggest testing systematically the 200, 400 and 600 values always uninstalling and reinstalling.

  2. Apparently AWCC can interfere with process since I tried everything depicted below and it did not work until AWCC was uninstalled.

  3. The AGA and card were connected to my laptop the whole time

Could the AWCC interfere with other mxm cards like the Aetina_MXM_M3N1080 or the A4500 that you had a problem with. I have been having a problem with the Aetina_MXM_M3N1080 not working in the m18x r2 and m17x r4. I am going to try again but remove AWCC and see what happens.

Clevo P870DM3-G i9-9900k-32.0GB 2667mhz-GTX 1080 SLI

Alienware M18x R2 i7-3920xm-32GB DDR3-1600 RTX 3000

Alienware M17x R4 i7-3940XM 32GB DDR3-1600 P4000

Alienware M17x R4 i7-3940XM 20GB DDR3-1600 GTX 680M 120hz 3D

Precision m6700 i7-3840QM - 16.0GB DDR3 - GTX 970M
Precision m4700 i7-3610QM-8.00GB DDR3 @ 1600MHz-K2000M

GOBOXX SLM  G2721-i7-10875H RTX 3000-32GB ddr4(Gave to my Wife)



Link to comment
Share on other sites

3 hours ago, aldarxt said:

Could the AWCC interfere with other mxm cards like the Aetina_MXM_M3N1080 or the A4500 that you had a problem with. I have been having a problem with the Aetina_MXM_M3N1080 not working in the m18x r2 and m17x r4. I am going to try again but remove AWCC and see what happens.

No. I ran aetina 1080 perfectly fine in aw18 and awcc is installed. also works in m18xr2.

Alienware m18             : Intel Core i9 13900HX                  | nVidia GeForce RTX 4090    | K1675 | 2x1TB SSDs

Alienware Area-51M : Intel Core i9-9900K @ 5.3Ghz    | nVidia GeForce RTX 2080    | AX210 | Samsung 970 Evo+
Alienware M18x R2 :    Intel Core i7 3920XM @ 4.7Ghz | nVidia Quadro RTX 3000     | AX210 | Samsung 980 PRO
Clevo X170SM-G:         Intel Core i7 10700K @ Stock     | nVidia GeForce RTX 2070S | AX210 | 256GB+2x512GB

More Laps: M14x (555m) | M14xR2 (650m) | M15x (980m) | M17xR3 (880m) | M18xR1 (880m SLI) | 18 R1 (RTX 3000)

DT: Aurora R4 (i9 10980XE/RTX 4070) | Area-51 R2 (22-Core Xeon/2x Titan V) | SR-2 [2x6-Core/3x980Ti] | Mac Studio


CS Studios YouTube: https://www.youtube.com/c/CSStudiosYT

Link to comment
Share on other sites

3 hours ago, ssj92 said:

No. I ran aetina 1080 perfectly fine in aw18 and awcc is installed. also works in m18xr2.

Thanks anyway but I just tried again in the m17x r4 and the GTX 1080 just won't work. I get code 43 and searched around again and nothing works. Tried uninstalling AWCC and OSD also Intel HD Graphics 4000 just to see what happens. The BIOS sees the 1080, so does GPU-Z but very limited info. The drivers install fine even tried standard drivers but they would not even allow it. This is why it gets scairy buying cards. I just had another goof-up buying a GTX-1070 for the P870DMG-3 and the guy sent me a GTX-1080. Now I have 2 different cards for it and can't run in SLI. I am thinking of asking if I could return the 1080 in exchange for a 1070. But maybe I should just flash the BIOS and get a 2080 or 3080 IDK!

Clevo P870DM3-G i9-9900k-32.0GB 2667mhz-GTX 1080 SLI

Alienware M18x R2 i7-3920xm-32GB DDR3-1600 RTX 3000

Alienware M17x R4 i7-3940XM 32GB DDR3-1600 P4000

Alienware M17x R4 i7-3940XM 20GB DDR3-1600 GTX 680M 120hz 3D

Precision m6700 i7-3840QM - 16.0GB DDR3 - GTX 970M
Precision m4700 i7-3610QM-8.00GB DDR3 @ 1600MHz-K2000M

GOBOXX SLM  G2721-i7-10875H RTX 3000-32GB ddr4(Gave to my Wife)



Link to comment
Share on other sites

  • 7 months later...
On 1/30/2023 at 11:45 PM, aldarxt said:

Thanks anyway but I just tried again in the m17x r4 and the GTX 1080 just won't work. I get code 43 and searched around again and nothing works. Tried uninstalling AWCC and OSD also Intel HD Graphics 4000 just to see what happens. The BIOS sees the 1080, so does GPU-Z but very limited info. The drivers install fine even tried standard drivers but they would not even allow it. This is why it gets scairy buying cards. I just had another goof-up buying a GTX-1070 for the P870DMG-3 and the guy sent me a GTX-1080. Now I have 2 different cards for it and can't run in SLI. I am thinking of asking if I could return the 1080 in exchange for a 1070. But maybe I should just flash the BIOS and get a 2080 or 3080 IDK!

Bro, did you modify your inf file?



HP Omen Transcend 16 13700HX/32GB 4800mhz/RTX 4070 105W/QHD 240Hz IPS.

Link to comment
Share on other sites

  • 3 months later...

Got my hands on one of these and looks like the performance is pretty impressive!



I got to test it with a 4080 and the Time Spy score is in the ballpark of what sites like notebookcheck have as stock which is about 26500.

With some tweaking it should be possible to increase this to maybe 27500 but benching is not that much fun when the Amplifier reduces performance by at least 10% 😄



So overall this means that for the relatively modest price of a 4070 Super one can get roughly 4080 mobile performance and with a 4070 Ti Super a performance that is roughly on par with a 4090 mobile - not too bad!





Link to comment
